Product Description

Working Pressure: 330 Bar (4800 psi)
Charging Rate (FAD): 270 lpm / 16.2m³ h / 9.5 cfm
Filling Time: 7 minutes 26 seconds (10 litres / 200 bar)
Air Filtration: ATL (To UNI EN 12021:2014 & AS/NZS1715:2009)
No Of Stages: 3
Power Source: Subaru Robin EX17 Petrol Motor
Motor: 9 HP / 6.7 Kw / 1550rpm
Unit Dimensions: 1180mm(L) x 540mm(W) x 690mm(H)
Unit Weight: 113.0 kg
Noise: 80 dB

• 2 filling valves with Gauge and Depressurisation standard
• Stainless Steel and Powder Coated Aluminium frame
• Interstage Condensate Separator decreases the condensation between stages in a position well aerated to maintain low temperate
• Crankshaft perfectly balanced
• Roller Crankshaft Bearings
• Oil Pump Lubrication
• Oil Filter and Magnet
• High quality materials resistant to thermal and dynamic stresses
• Air conveyor designed for high heat exchange efficiency
• Steel valves for longer life and greater performance
• Filter cartridge properly sized for high air quality
• Low noise and vibration due to perfect balance of the pump unit
• Reliable petrol motors designed and built by Subaru
